SPECIFICATIONS:

• Capnograph adopts mainstream method to measure the end-tidal carbon dioxide, airway respiration rate and other parameters.
• It can detect pulmonary ventilation function and reflect the circulation and pulmonary blood flow condition as well as indirectly reflect the alveolar ventilation, which is applicable for use in pre-hospital emergency transfer, emergency department, ICU, operating room, neonatology, respiratory department and other environments.
• The application is suitable for adult, pediatric and neonate patients.
• The capnograph connects with the patients respiratory tract by the airway adapter and breathing tube.

Features:

• End-tidal CO2 measurement function.
• Respiration rate measurement function.
• Over-limit alarm function for end-tidal CO2 and respiration rate.
• Low battery alarm function.
• Waterproof and dustproof degree: IPX2.
• Etco2 measuring range: 0-150 mmHg.
• AwRR measuring range: 2-150 rpm.
• 1.3" true colour, LCD, user friendly interface, easy to operate.
• Compact and lightweight design.
• Audio-Visual alarm system.
