Description
SPECIFICATIONS:
The MS710 Calibration Syringe is a medical-grade precision instrument engineered to verify, maintain, and calibrate spirometry devices and lung function equipment. Designed to meet strict international ATS/ERS quality standards, the MS710 delivers a highly accurate volumetric gas discharge. This makes it an essential tool for daily quality control procedures in pulmonary function laboratories, respiratory clinics, hospitals, and occupational health screening centers.
Key Features
- Dual-Volume 2L / 3L Calibration Function: Outfitted with an adjustable mechanical limit circlip that allows operators to easily configure and toggle the device to discharge either a precise 2-Litre or 3-Litre volume.
- Exceptional Volumetric Accuracy: Precision-machined to guarantee an absolute volume delivery accuracy rating of ±0.4%, drastically reducing measurement errors during device calibration checks.
- Ultra-Smooth Plunger Action: Features an anodized aluminum cylinder with a meticulously polished interior wall. This delivers low-resistance piston movement, ensuring a fluent, consistent push and pull to simulate true physiological airflow.
- Superior Gas Tightness & Seals: Built with industrial-grade mechanical airtight gaskets that completely eliminate micro-leaks or drop-offs in pressure, ensuring traceably consistent results.
- Universal Port Compatibility: Designed with a universal tapered port connection that fits effortlessly onto a wide range of leading desktop and portable spirometer models, including the Contec SP100 and SP10, as well as MIR and Vitalograph devices.
- Lightweight & Portable Build: Features a streamlined, compact chassis profile weighing under 2.5 kg, allowing clinical technicians to move the device smoothly between bedside stations or separate screening facilities.
Technical Specifications
- Model Configuration: MS710 (Manual Calibration Series)
- Volume Options Range: 3 Liters
- Volumetric Accuracy Performance: ± 0.4%
- Cylinder Construction: Anodized Aluminum with Polished Inner Liners
- Standard Regulatory Compliance: Designed to comply with global ATS/ERS spirometry standards.
- Environmental Working Tolerance: 0°C to +50°C | 30% to 100% RH
Package Accessories Checklist
The MS710 Spirometer Calibration Syringe ships as a self-contained quality control kit inside a secure, protective transport box:
- 1 × MS710 Core Calibration Cylinder Assembly
- 1 × Flexible Flexible Connection Extension Tube
- 1 × Universal Calibration Connector Mouthpiece
- 1 × Adjustable Mechanical Volume Limit Circlip
- 1 × Protective Dust Port Cover
- 1 × User Operating Manual
